The frequency ranges listed are for reference only and are not exhaustive. If you want other frequency ranges, please contact us for customization
Frequency range: 50MHZ to 700GHZ;
Application fields: used in civil, military, aerospace, space technology, etc.;
Technical features: low insertion loss, high isolator, high power, can be customized and produced according to customer requirements.
| band pass frequency(MHz) | Insertion loss(dB) | standing wave ratio | out of band suppression | power(w) | Connection form | temperature(°C) | size (Length * width * height mm) |
| 50~80 | 8 | 1.5 | 60dB @88~108MHz | 5 | SMA | -40~+85 | 30×20×12 |
| (BW 2.5MHz) | 40dB @Fc±6.5MHz | ||||||
| 130~700 | 3.5 | 1.5 | 40dB @Fc±6.5MHz | 2 | BNC,N,SMA | -30~+70 | 48×25×20 |
| (BW ~50MHz) | |||||||
| 136~200 | 2 | 1.3 | 60dB @88~108MHz | 100 | N,SMA | -40~+85 | 250×166×54 |
| (BW 2.5MHz) | 40dB @F0±6.5MHz | ||||||
| 136~200 | 2 | 1.5 | 40dB @Fc±6.5MHz | 100 | N,SMA | -40~+85 | 338×151×48 |
| (BW 9MHz) | |||||||
| 149~165 | 2 | 1.3 | 60dB @88~108MHz | 10 | N,SMA | -40~+85 | 60×20×20 |
| 40dB @225~400MHz | |||||||
| 200~400 | 3 | 1.5 | 20dB @F0±25MHz | 2 | SMA | -40~+85 | 40.4×12×10 |
| (BW 10MHz) | |||||||
| 220 | 3 | 1.45 | 60dB @Fc±10MHz | 100 | N,SMA | -40~+85 | 106×73×65 |
| 220~230 | 3.5 | 1.3 | 60dB @F0±10MHz | 50 | N,SMA | -40~+85 | 73×73×50 |
| (BW ~0.7MHz) | 35dB @F0±4.3MHz |
