The frequency ranges listed are for reference only and are not exhaustive. If you want other frequency ranges, please contact us for customization
Frequency range: 130MHZ to 3000GHZ;
Application fields: used in civil, military, aerospace, space technology, etc.;
Technical features: low insertion loss, high isolator, high power, can be customized and produced according to customer requirements
| band pass frequency(MHz) | Insertion loss(dB) | standing wave ratio | out of band suppression | power(W) | Connection form | temperature(°C) | size （Length * width * height mm) |
| 130~700 | 3.5 | 1.5 | 40dB @Fc±6.5MHz | 2 | BNC,N,SMA | -30~+70 | 48×25×20 |
| (BW ~50MHz) | |||||||
| 200~400 | 3 | 1.5 | 20dB @F0±25MHz | 2 | SMA | -40~+85 | 40.4×12×10 |
| (BW 10MHz) | |||||||
| 380~400 | 2 | 1.3 | 40dB @Fc±5MHz | 50 | N,SMA | -20~+60 | 135×87×68 |
| (BW ~5MHz) | |||||||
| 380~420 | 0.7 | 1.4 | 35dB @Fc±40MHz | 100 | N,SMA | -40~+85 | 216×96×42 |
| 380~500 | 2 | 1.3 | 40dB @F0±8MHz | 100 | N,SMA | -40~+85 | 93×93×64 |
| (BW ~8MHz) | 60dB @88~108MHz | ||||||
| 390~470 | 2 | 1.3 | 60dB @88~108MHz | 80 | N,SMA | -40~+85 | 106×73×65 |
| (BW ~7MHz) | 40dB @F0±8.5MHz | ||||||
| 435~800 | 2 | 1.3 | 40dB @F0±50MHz | 100 | N,SMA | -40~+85 | 83×83×58 |
| (BW 10MHz) | |||||||
| 450~600 | 1 | 1.3 | 70dB @Fc±78MHz | 50 | N,SMA | -40~+85 | 180×120×58 |
| (BW 10~150MHz) | 50dB @Fc±24MHz |
