The frequency ranges listed are for reference only and are not exhaustive. If you want other frequency ranges, please contact us for customization
Frequency range: 1MHZ to 20GHZ;
Application fields: used in civil, military, aerospace, space technology, etc.;
Technical features: low insertion loss, high isolator, high power, can be customized and produced according to customer requirements
| band pass frequency(MHz) | Insertion loss(dB) | standing wave ratio | out of band suppression | power(w) | Connection form | temperature(°C) | size(Length . width . height mm) |
| DC-108 | 2 | 1.5 | 40dB @150~2000MHz | 10 | SMA | -40~+85 | 35×12×8 |
| DC-170 | 0.5 | 1.3 | 45dB @500~2000MHz | 100 | N,SMA | -40~+85 | 90×80×22 |
| 850~865 | 45dB @1710~2560MHz | ||||||
| 5~95 | 1.5 | 1.4 | 45dB@105~500MHz | 10 | SMA,N | -25~+55 | 160×54×20 |
| 5~285 | 2 | 1.5 | 45dB @330~650MHz | 5 | SMA | -40~+85 | 40.4×12×10 |
| DC-400 | 1 | 1.5 | 20dB @500~1000MHz | 40 | SMA | -40~+85 | 48×25×16 |
| DC-490 | 0.5 | 1.3 | 45dB @850MHz | 100 | N,SMA | -40~+85 | 180×26×20 |
| band pass frequency(MHz) | Insertion loss(dB) | standing wave ratio | out of band suppression | power(w) | Connection form | temperature(°C) | size(Length . width . height mm) |
| DC-500 | 1.5 | 1.5 | 40dB @700~2000MHz | 50 | N,SMA | -20~+55 | 180×26×20 |
| DC-1500 | 1.5 | 1.5 | 40dB @1700~3000MHz | 50 | N,SMA | -20~+55 | 180×26×20 |
| DC-894 | 1.5 | 1.5 | 70dB @1760~2668MHz | 5 | SMA | -40~+85 | 45×20×12 |
| DC-900 | 1.2 | 1.8 | 50dB @1.2~2.0GHz | 30 | SMA | -40~+85 | 88×63×12 |
| DC-1000 | 1.5 | 1.5 | 50dB @1.4~1.9GHz | 30 | SMA | -40~+85 | 190×48×12 |
| DC-1000 | 0.55 | 1.5 | 40dB @2000~3000MHz | 100 | SMA, N | -40~+85 | 158×30×24 |
| DC-1700 | 0.55 | 1.5 | 40dB @2800~6000MHz | 100 | SMA, N | -40~+85 | 98×28×23 |
| DC-1800 | 0.2 | 1.5 | 20dB @3220~3253MHz | 10 | SMA | -40~+85 | 64×20×16 |
| 25dB @4830~4879MHz | |||||||
| 30dB @6440~6506MHz |
