The frequency ranges listed are for reference only and are not exhaustive. If you want other frequency ranges, please contact us for customization
Frequency range: frequency up to 20GHZ;
Application fields: used in civil, military, aerospace, space technology, etc.;
Technical features: low insertion loss, high isolator, high power, can be customized and produced according to customer requirements
| frequency range(MHz) | Insertion loss(dB) | Isolation(dB) | standing wave ratio | power(W) | Connection form | temperature range(°C) | size(Length *width * height mm) | |
| TX | 30~520 | 0.8 | 45 | 1.45 | 50 | N, SMA | -30~+70 | 71×91×22 |
| RX | 698~2700 | |||||||
| TX | 45.5~69.0 | 3 | 15 | 1.5 | 2 | BNC, N, SMA | -30~+70 | 40×53×20 |
| RX | 80.0~103.3 | |||||||
| 60~800MHz | 0.5 | 80 | 1.25 | 100 | N, SMA | -30~+70 | 140×73×33 | |
| TX->RX >30MHz | ||||||||
| TX | 136~174 | 0.8 | 70 | 1.45 | 100 | N, SMA | -40~+70 | 95×115×25 |
| RX | 400~470 | |||||||
| TX | 136~174 | 1 | 70 | 1.5 | 5 | N, SMA | -40~+70 | 44×50×22 |
| RX | 400~470 | |||||||
| frequency range(MHz) | Insertion loss(dB) | Isolation(dB) | standing wave ratio | power(W) | Connection form | temperature range(°C) | size(Length *width * height mm) | |
| Low | 136~174 | 1 | 30 | 1.5 | 5 | N, SMA | -10~+60 | 58×54×20 |
| High | 400~470 | |||||||
| TX | 145~158 | 1 | 80 | 1.3 | 100 | N, SMA | -40~+85 | 320×420×100 |
| RX | 168~180 | |||||||
| 140~170MHz | 1.5 | 80 | 1.3 | 100 | N, SMA | -30~+70 | 310×219×156 | |
| TX->RX 5MHz | ||||||||
| 148~174MHz | 1.8 | 80 | 1.3 | 100 | N, SMA | -30~+65 | 483×192×178 | |
| TX->RX 4.6MHz | ||||||||
| TX | 151.06~154.125 | 1 | 65 | 1.35 | 50 | N, SMA | -20~+65 | 148×310×156 |
| RX | 158.765~160.09 | |||||||
