The frequency ranges listed are for reference only and are not exhaustive. If you want other frequency ranges, please contact us for customization
Frequency range: 440MHZ to 3800GHZ;
Application fields: used in civil, military, aerospace, space technology, etc.;
Technical features: low insertion loss, high isolator, high power, can be customized and produced according to customer requirement
| band stop frequency(MHz) | passband frequency | stop band suppressionMin(dB) | standing wave ratio | Insertion loss(dB) | power(W) | Connection form | temperature range(°C) | Overall dimensions (Length * width* height mm) |
| 440~452 | DC~420MHz | 35 | 1.5 | 1 | 50 | SMA, N | -30~+70 | 323×111×59 |
| 475~1000MHz | ||||||||
| 460~520 | DC~402MHz | 65 | 1.8 | 2.5 | 2 | SMA | -55~+85 | 40×12×10 |
| 578~2000MHz | ||||||||
| 462.425 | 450~456MHz | 20 | 1.45 | 1.5 | 50 | SMA, N | -40~+80 | 110×60×63 |
| 462~467MHz | ||||||||
| 616~638 | 50~576MHz | 40 | 1.8 | 2.5 | 5 | SMA, N | -55~+85 | 35×25×20 |
| 678~800MHz | ||||||||
| 791~821 | DC~700MHz | 40 | 1.7 | 1.5 | 100 | SMA, N | -20~+55 | 280×140×48 |
| 832~2000MHz |
| band stop frequency(MHz) | passband frequency | stop band suppressionMin(dB) | standing wave ratio | Insertion loss(dB) | power(W) | Connection form | temperature range(°C) | Overall dimensions(Length * width* height mm) |
| 824~849 | DC~785MHz | 40 | 2 | 1.5 | 50 | SMA | -55~+85 | 255×81×53 |
| 885~1249MHz | ||||||||
| 832~837 | DC~822MHz | 40 | 2 | 1.5 | 50 | SMA | -55~+85 | 255×88×53 |
| 847~1500MHz | ||||||||
| 868~870 | DC~821MHz | 50 | 1.3 | 0.5 | 50 | SMA, N | -30~+70 | 158×67×43 |
| 925~1200MHz | ||||||||
| 870~880 | DC-860MHz | 40 | 2 | 2 | 100 | SMA, N | -20~+65 | 247×100×50 |
| 885-2500MHz | ||||||||
| 930~965 | DC~900MHz | 40 | 2 | 1.5 | 50 | SMA | -55~+85 | 295×67×43 |
| 995~2200MHz | ||||||||
| 1020~1100 | DC~920MHz | 45 | 2 | 1.5 | 5 | SMA | -40~+85 | 165×111×51 |
| 1200~2100MHz |
