The frequency ranges listed are for reference only and are not exhaustive. If you want other frequency ranges, please contact us for customization
Frequency range: frequency up to 40GHZ;
Application fields: used in civil, military, aerospace, space technology, etc.;
Technical features: low insertion loss, high isolator, high power, can be customized and produced according to customer requirements.
| Frequency range (MHZ) | Insertion loss (db) | standing wave ratio | out of band suppression | Connection method | temperature | Dimensions (length*width*height) mm | Power(W) |
| 290-320 | 1.0 | 1.3 | ≥100dB @230-270MHz ≥100dB @340-380MHz | 7/16，N,SMA | -40～ +70 | 205*205*80 | 200 |
| 360-380 | 1.0 | 1.3 | ≥85dB @DC-340MHz ≥85dB @400-1650MHz | 7/16，N,SMA | -40～ +70 | 220*115*63 | 200 |
| 703-894 | 1.5 | 1.3 | ≥20dB @F0±5MHz ≥55dB @F0±45MHzMHz | N,SMA | -40～ +70 | 120*65*45 | 200 |
| 885-889 | 5.0 | 1.3 | ≥50dB @DC-884MHz | 7/16，N,SMA | -40～ +70 | 260*115*60 | 50 |
| 1429-1520 | 0.8 | 1.3 | ≥65dB @700-900MHz ≥90dB @1560-1590MHz ≥65dB @1700-2700MHz | N,SMA | -40～ +70 | 178*65*16 | 50 |
| Frequency range (MHZ) | Insertion loss (db) | standing wave ratio | out of band suppression | Connection method | temperature | Dimensions (length*width*height) mm | Power(W) |
| 1556-1592 | 2.6 | 1.3 | ≥30dB @1600-1605MHz ≥50dB @1605-1610MHz ≥70dB @1610-1628MHz | mcx-k | -40～ +70 | 107*32*16 | 50 |
| 1610-1628 | 2.6 | 1.3 | ≥85dB @1559-1592MHz ≥40dB @1592-1600MHz | mcx-k | -40～ +70 | 79*35*22 | 50 |
| 2070-2120 | 0.9 | 1.2 | ≥85dB @2020-2040MHz ≥40dB @500-2020MHz | N-K | -40～ +70 | 145*75*42 | 300 |
| 2850-3150 | 0.5 | 1.3 | ≥40dB @2700-2800MHz ≥20dB @3200-3500MHz | N-K | -40～ +70 | 58*58*38 | 200 |
| 17700-21200 | 0.4 | 1.3 | ≥60dB @27500-31000MHz | FBP220 | -40～ +70 | 35*24*24 | 500 |
