The frequency ranges listed are for reference only and are not exhaustive. If you want other frequency ranges, please contact us for customization
Frequency range: 87MHZ to 40GHZ;
Application fields: used in civil, military, aerospace, space technology, etc.;
Technical features: low insertion loss, high isolator, high power, can be customized and produced according to customer requirements
| band pass frequency(GHz) | Insertion loss(dB) | Isolation（dB) | Enter (standing wave ratio) | output(standing wave ratio) | Pass power（W） | Reflected power（W） | Connection form | temperature(°C) | size（Length * width * height mm) |
| 0.136~0.48 | 0.8 | 18 | 1.5 | 1.4 | 20 | 3 | SMA, BNC | -30~+70 | 245×174×16 |
| 0.136~0.52 | 1.1 | 18 | 1.35 | 1.35 | 50 | 2 | SMA, N | -40~+85 | 260×159×21 |
| 0.136~0.96 | 1.1 | 18 | 1.35 | 1.35 | 50 | 2 | SMA, N | -40~+85 | 260×159×21 |
| 0.35~4.0 | 4.5 | 18 | 1.5 | 1.4 | 10 | 3 | SMA | -35~+65 | 144×103×15.5 |
| 0.4~4.0 | 4.5 | 18 | 1.5 | 1.4 | 10 | 3 | SMA | -35~+65 | 144×103×15.5 |
| 0.5~2.0 | 1.5 | 20 | 1.4 | 1.2 | 30 | 3 | SMA | -55~+85 | 108×80×10 |
| 0.5~6.0 | 2.8 | 18 | 1.5 | 1.5 | 30 | 3 | SMA | -40~+85 | 110×140×10 |
| 0.698~2.7 | 1.2 | 16 | 1.35 | 1.35 | 50 | 2 | SMA, N | -40~+85 | 199×106×21 |
| 0.8~2.5 | |||||||||
| 0.8~2.7 |
| band pass frequency(GHz) | Insertion loss(dB) | Isolation（dB) | Enter (standing wave ratio) | output(standing wave ratio) | Pass power（W） | Reflected power（W） | Connection form | temperature(°C) | size（Length * width * height mm) |
| 0.8~2.5 | 1.3 | 20 | 1.4 | 1.3 | 30 | 3 | SMA | -55~+85 | 108×75×10 |
| 1.0~2.0 | 1 | 20 | 1.3 | 1.3 | 30 | 3 | SMA | -55~+85 | 108×63×10 |
| 1.0~4.0 | 1.5 | 20 | 1.4 | 1.3 | 30 | 3 | SMA | -55~+85 | 108×63×10 |
| 2.0~4.0 | 0.8 | 20 | 1.3 | 1.3 | 30 | 3 | SMA | -55~+85 | 108×63×10 |
| 2.0~8.0 | 1.8 | 18 | 1.4 | 1.3 | 30 | 3 | SMA | -55~+85 | 108×63×10 |
| 4.0~8.0 | 1.2 | 18 | 1.5 | 1.4 | 30 | 3 | SMA | -55~+85 | 108×63×10 |
| 4.0~18.0 | 1.8 | 15 | 2 | 1.8 | 30 | 3 | SMA | -55~+85 | 101.5×62×10 |
| 5.0~6.0 | 1 | 18 | 1.4 | 1.3 | 10 | 2 | SMA | -55~+85 | 113×48×14 |
